Jsme autorizovaní agenti innolux pro průmyslové lcd panely, cog, mlha, lcm.
Lcd panel innolux obsahuje 2,8 '', 3,5'', 4,3 '', 5,0'' a 7,0''
Since we have our own factory, we use innolux lcd panels and develop our own lcm.
Níže je uveden originál innolux cog, fog a lcm, které dodáváme.
| Velikost | Typ | Rozlišení | Model | Jasnost | Ntsc | Kontrast | Obrys (mm) h * w * t | Lcm aa (mm) | Pin | Rozhraní | Úhel zobrazení | Režim | Pracovní teplota | Teplota skladování |
| 3.5" | Lcm | 320x240 | Lq035nc111 | 300 | 60% | 400 | 76.9*63.9*3.26 | 70.08*52.56 | 54.00 | Ttl | 60/60/50/55 | -20 ~ 70 | -30 ~ 80 | |
| 5.6'' | Lcm | 640x480 | At056tn52 v.3 | 200 | 500 | 126.5*100*5.7 | 115.2*86.4 | 50 | Ttl | 70/70/50/70 | -20 ~ 70 | -30 ~ 80 | ||
| 5.6'' | Lcm | 640x480 | At056tn53 | 350 | 75% | 500 | 126.5*100*5.7 | 112.896*84.672 | 40 | 24-bit rgb | 6 Hodina | Přenosný | -20 ~ 70 | -30 ~ 80 |
| 5.7" | Lcm | 640*480 | G057VCE-TH1 | 450 | 80% | 600 | 144*104.6*12.3 | 115.2*86.4 | 40 | Ttl | 88/88/88/88 | -30 ~ 85 | -40 ~ 85 | |
| 6,5" | Lcm | 800*480 | At065tn14 | 500 | 75% | 500 | 155.2*89.4*5.5 | 143.400*76.704 | 50 | 24-bit rgb | 6 Hodina | Přenosný | -30 ~ 85 | -30 ~ 85 |
| 7" | Lcm | 800*480 | At070tn83 | 300 | 75% | 500 | 165*104*5.5 | 152.4*91.44 | 40 | 24-bit rgb | 6 Hodina | Přenosný | -20 ~ 70 | -30 ~ 80 |
| 7" | Lcm | 800*480 | At070tn92 | 250 | 75% | 500 | 164.9*100*5.7 | 154.08*85.92 | 50 | 24-bit rgb | 6 Hodina | Přenosný | -20 ~ 70 | -30 ~ 80 |
| 7" | Lcm | 800*480 | At070tn94 | 450 | 75% | 500 | 164.9*100*5.7 | 154.08*85.92 | 50 | 24-bit rgb | 6 Hodina | Přenosný | -20 ~ 70 | -30 ~ 80 |
| 7" | Lcm | 800x480 | G070ACE-L01 | 500 | 70% | 800 | 170*110*6 | 152.4*91.44 | 30 | Lvds | 89/89/89/89 | -30 ~ 85 | -40 ~ 90 | |
| 7" | Lcm | 800x480 | G070ACE-LH3 | 500 | 70% (min) | 800 | 165*104*8.63 | 152.4*91.44 | 30 | Lvds | 89/89/89/89 | -30 ~ 85 | -40 ~ 85 | |
| 7" | Lcm | 1024*600 | NJ070NA-23A | 500 | 75% | 800 | 164.9*100*4.8 | 154.2144*85.92 | 40 | Lvds | 6 Hodina | Přenosný | -20 ~ 70 | -30 ~ 80 |
| 23.8" | Lcm | 800*480 | At080tn64 | 450 | 75% | 500 | 192.8*116.9*6.4 | 176.64*99.36 | 50 | 24-bit rgb | 6 Hodina | Přenosný | -30 ~ 85 | -30 ~ 85 |
| 9' | Lcm | 800*480 | At090tn12 | 250 | 75% | 500 | 211.1*126.5*5.9 | 198.000*111.696 | 24-bit rgb | 6 Hodina | Přenosný | -20 ~ 70 | -30 ~ 80 | |
| 10.1'' | Lcm | 1280x800 | G101ICE-L01 | 500 | 54% | 800 | 230.7*152.55*6.5 | 216.96*135.60 | 40 | Lvds | 85/85/85/85 | -20 ~ 65 | -25 ~ 70 | |
| 10.1'' | Lcm | 1280x800 | G101ICE-LH1 | 500 | 70% | 800 | 230.7*152.55*6.5 | 216.96*135.6 | 30 | Lvds | 88/88/88/88 | -30 ~ 80 | -40 ~ 85 | |
| 10.2'' | Lcm | 800*480 | At102tn03 | 350 | 75% | 300 | 235.0*145.8*6.1 | 222.0*132.48 | 60 | 24-bit rgb | 6 Hodina | Přenosný | -30 ~ 85 | -30 ~ 85 |
| 10.4'' | Lcm | 800x600 | G104AGE-L02 | 400 | 53% | 700 | 243*184*8.0 | 211.2*158.4 | 20 | LVDS-LED-5pin | 80/80/70/70 | -30 ~ 85 | -30 ~ 85 | |
| 10.4'' | Lcm | 960x1280 | G104ACJ-L01 | 900////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////// | <En> | 1000 | 173,4*228,7*13,77 | 158.4*211.2 | 50.00 | LVDS-LED-10pin | 85/85/85/85 5/85 | -40 ~ 85 | -40 ~ 90 | |
| 10.4'' | Lcm | 1024x768 | G104XCE-L01 | 500 | 80% | 1000 | 225.5*176.3*8.7 | 210.4*157.8 | 30 | LVDS-LED 10pin | 88/88/88/88 | -30 ~ 85 | -30 ~ 85 | |
| 12.1'' | Lcm | 800*600 | G121ACE-LH1 | 450 | 80% | 1000 | 260.5*204.0*8.4 | 246*184.5 | 30 | LVDS-LED-5pin | 88/88/88/88 | -30 ~ 85 | -30 ~ 85 | |
| 12.1'' | Lcm | 1280x800 | G121ICE-L01 | 600 | 80% | 1000 | 278*184*10 | 261.12*163.2 | 30 | Lvds | 85/85/85/85 | -30 ~ 80 | -30 ~ 85 | |
| 12.1'' | Lcm | 1280x800 | G121ICE-L02 | 400 | 80% | 278*184*10 | 261.12*163.2 | 30 | Lvds | 88/88/88/88 | -20 ~ 70 | -20 ~ 70 | ||
| 12.1'' | Lcm | 1024x768 | G121XCE-L01 | 600 | 73% | 1000 | 260.5*204.0*8.4 | 245.76*184.32 | 20 | LVDS-LED-10pin | 89/89/89/89 | -30 ~ 85 | -40 ~ 90 | |
| 12.1'' | Lcm | 1024x768 | G121XCE-L02 | 500 | 80% | 1000 | 260.5*204.0*8.4 | 245.76*184.32 | 20 | LVDS-LED-10pin | 89/89/89/89 | -30 ~ 70 | -40 ~ 80 | |
| 15.0'' | Lcm | 1024x768 | G150XNE-L01 | 500 | 70% | 2500 | 326.5*253.5*9.1 | 304.1*228.1 | 20 | LVDS-LED-5pin | 88/88/88/88 | -30 ~ 80 | -40 ~ 80 | |
| 15.0'' | Lcm | 1024x768 | G150XNE-L02 | 350 | 70% | 2500 | 326.5*253.5*9.1 | 304.1*228.1 | 20 | LVDS-LED-5pin | 88/88/88/88 | -30 ~ 70 | -40 ~ 70 | |
| 15.6'' | Lcm | 1920x1080 | G156HCE-L01 | 450 | 72% | 800 | 363.8*215.9*9.3 | 344.16*193.59 | 40 | Lvds | 89/89/89/89 | -30 ~ 85 | -40 ~ 90 | |
| 15.6'' | Lcm | 1920x1080 | G156HCE-LN1 | 350 | 70% | 800 | 363.8*215.9*9.3 | 344.16*193.59 | 40 | Lvds | 89/89/89/89 | 0 ~ 60 | -20 ~ 70 | |
| 17.0'' | Lcm | 1920x1200 | G170J1-LE1 | 600 | 70% | 2000 | 386.8*250.8*18.6 | 365.76*228.6 | 30 | LVDS-LED-10pin | 88/88/88/88 | -20 ~ 80 | -40 ~ 90 | |
| 18.5" | Lcm | 1366x768 | G185BGE-L01 | 300 | 72% | 1000 | 430.37*254.6*16.1 | 409.8*230.4 | 30 | LVDS-LED-5pin | 85/85/80/80 | 0 ~ 60 | -20 ~ 60 | |
| 20.0'' | Lcm | 1920x1080 | M200HJJ-L20 | 250 | 72% | 3000 | 459*263*11.32 | 434.88*238.68 | 30 | LVDS-LED 6pin | 89/89/89/89 | 0 ~ 50 | -20 ~ 60 | |
| 21.5'' | Lcm | 1920x1080 | G215HCJ-L01 | 400 | 72% | 1000 | 497.6*287*13.52 | 476.064*267.786 | 30 | LVDS-LED 9pin | 89/89/89/89 | 0 ~ 60 | -20 ~ 60 | |
| 23.8" | Lcm | 1920x1080 | G238HCJ-L01 | 350 | 72% | 1000 | 543*317.4*11.1 | 527.04*296.46 | 30 | LVDS-LED-6pin | 89/89/89/89 | 0 ~ 50 | -20 ~ 60 |
Velikost | Typ | Rozlišení | Model no | Lcm (mm) | Pin | Rozhraní | Úhel zobrazení | Pracovní teplota |
7 | Cog | 800*480 | ZB070BF-09G | 152.4*91.44 | 108 | 6 hodin | -20 ~ 70 | |
7 | Mlha | 800*480 | NE070NB-04F (krátké fpc) | 85.92*154.08 | 50 | 24-bit rgb | 6 hodin | -20 ~ 70 |
Mlha | 800*480 | NE070NB-04G(long fpc) | 85.92*154.08 | 50 | 24-bit rgb | 6 hodin | -20 ~ 70 | |
Posted on 8 september 2010 by john cook | Mlha | 800*600 | EE080NA-06A | 162.0*121.5 | 50 | 24-bit rgb | 6 hodin | -20 ~ 70 |
10.1 | Mlha | 1280*800 | EE101IA-01D | 135.60*216.96 | 40 | Lvds | Ips | -20 ~ 70 |
10.4 | Mlha | 800*600 | G104AG1-A01 | 211.2*158.4 | 60 | 24-bit rgb | 6 hodin | '-10-50 |
Mlha | 1024*768 | ZE104IA-03D | 210.43*157.82 | 30 | Lvds | Ips | -30 ~ 80 | |
11.6 (+ + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + | Mlha | 1366*768 | HE116BB-01A | 256.125*144.00 | 30 | Edp | Ips | -10 ~ 50 |
15.6 | Mlha | 1920*1080 | ZE156IA-02B | 154.08*85.92 | 30 | Edp | Ips | -20 ~ 70 |
Mlha | 1920*1080 | ZE156BB-01A | 154.08*85.92 | 30 | Edp | Ips | -0 ~ 70 |
Innolux original cog, fog, lcm pro
Stabilní nabídka
Originální lcm a vlastní lcm k dispozici
Tn/ips/all/free/wide viewing angle
Normální a široká pracovní teplota
Vývoj přenos desky
Kapacitní dotyková obrazovka/optická lepenka
Indutrial kontrola a lékařská aplikace
The kingtech innolux original cog, fog, and lcm tft lcd displays are versatile solutions designed for a variety of applications. Ideální pro zemědělské vybavení, zdravotnické prostředky, herní konzoly a inteligentní domácí systémy, tyto displeje nabízejí mimořádnou jasnost, trvanlivostA výkon. Věř kingtech, že poskytne moderní technologii, která zlepšuje funkčnost a uživatelské zkušenosti v mnoha odvětvích.
